识别号：omj-09x ( 前壁门楣安装 ) omj-09xa ( 轿顶安装 ) omj-09xb ( 轿架直梁安装 )
特 征：1.采用同步带传动 , 无滑差 , 无需润滑 , 运行平稳噪音更低
2.采用集成轿门锁功能的异步门刀，实现门挂板上安装，符号新国标要求
3.采用 vvvf 变频控制技术 , 调试简便 , 安全可靠
4.采用扁平型电机 ,s 形压制导轨 , 结构更紧凑
serial no:omj-09x (on car front-wall installation) omj-09xa (car top installation) omj-09xb (straight beam installation)
feature：1.the synchronous belt drive directly, no slip, no lubrication, running smoothly in lower nois
2.the asynchronous vane is equipped with door lock function, installation on door hanger, and qualified by new national standard
3. vvvf control system, safe, reliable, easy to adjust
4. flat shape motor, s-shaped guide rail, more compact structure
omj-09xa 中分三相变频异步门机( 轿顶式)示意图
2-leafs center opening vvvf asynchronous door operator
(car top installation)schematic diagram
omj-09xb 中分三相变频异步门机( 轿架直梁式)示意图
2-leafs center opening vvvf asynchronous door operator
(straight beam installation)schematic diagram
omj-09x 中分三相变频异步门机( 前壁门楣式)示意图
2-leafs center opening vvvf asynchronous door operator
(on car front-wall installation)schematic diagram
门控制器配置（选配）inverter(optional):
|
|
|
| olvf200-1 | nice-d-a-sop4-ol2 | aad03040d-ol |
前壁门楣安装 for car front-wall installation:
 | |||
| 门楣安装支架 installation brackets drawing no:omj16-1 |
轿顶安装 for car top installation:
 |  |  | |
| 轿顶安装支架
installation brackets drawing no:omj01-01 / omj01-02 | 轿顶安装 c 型管 ( 选配 ) fixing pipe for car top installation(optional) drawing no:omj01-03 | 加强安装支架 strengthened installation bracket drawing no:omj11-1b |
轿架直梁安装 for straight beam installation:
 |  |  |  |
| 安装臂组件 installation arm module drawing no:omj01.23d | 直拉杆组件/长拉杆组件 straight tie-rod module / long tie-rod module drawing no:omj01.25 / omj01.24 | 大拉钩/小拉钩 big pull hook / small pull hook drawing no:omj01.26 / omj01.32 | 安装侧板组 side bracket for installation drawing no:omj01.7 |
