识别号：omj-01 ( 轿架直梁安装 ) omj-01d ( 轿顶安装 )
特 征：1.采用新型同步带传动 , 无滑差 , 无需润滑 , 运行平稳噪音更低
2.采用异步门刀 , 可实现门板与挂板上安装 , 具有机械锁紧力
3.采用 vvvf 变频控制技术 , 可选配开门限制装置 , 安全可靠 , 调试简便
4.采用 s 形压制导轨 , 结构更紧凑
serial no：omj-01 (straight beam installation) omj-01d (car top installation)
feature：1.the synchronous belt drive directly, no slip, no lubrication, running smoothly in lower noise
2.asynchronous door vane used, installation on door panel or door hanger, with mechanical blocking force.
3.vvvf control system, door opening limiter, safe, reliable, easy to adjust
4.press rail in s-shaped, more compact structure
omj 系列 中分三相变频异步门机安装示意图
2-leafs center opening vvvf door operator installation schematic diagram
通用件 general parts:
|
|
|
| 变频器 ( 可选 ) inverter(optional) drawing no:nice-d-a-sop4-ol2 | 松下 aad03040d-ol | 松下 drawing no:aad03011dk |
轿架直梁安装 for straight beam installation:
 |  |  |  |
| 安装臂组件 installation arm module drawing no:omj01.23d | 直拉杆组件/长拉杆组件 straight tie-rod module / long tie-rod module drawing no:omj01.25 / omj01.24 | 大拉钩/小拉钩 big pull hook / small pull hook drawing no:omj01.26 / omj01.32 | 安装侧板组 side bracket for installation drawing no:omj01.7 |
轿顶安装 for car top installation:
 |  |  | |
| 轿顶安装支架
installation brackets drawing no:omj01-01 / omj01-02 | 加强安装支架 strengthened installation bracket drawing no:omj11-1b | 轿顶安装 c 型管 ( 选配 ) |
