识别号：omj-200a( 轿顶安装) omj-200b( 轿架直梁安装)
特 征：1、采用永磁同步大功率电机，额定转矩大，高效节能环保
2、采用集成轿门锁功能的同步门刀, 真正实现厅轿门同步开闭
3、采用同步带直接传动, 无滑差, 运行平稳噪音更低
4、采用全闭环伺服控制技术, 调试简便, 控制精度高
5、门挂板设置防撞击脱落安全挂钩，安全可靠
serial no:omj-200a(car top installation) omj-200b(straight beam installation)
feature:1、the synchronous belt drive directly, no slip, no lubrication, running smoothly in lower noise
2、the asynchronous vane is equipped with door lock function, installation on door hanger, and qualified by new national standard
3、vvvf control system, safe, reliable, easy to adjust
4、flat shape motor, s-shaped guide rail, more compact structure
5、 flat shape motor, s-shaped guide rail, more compact structure
omj 系列 中分双折永磁同步门机安装示意图
2-leafs center opening vvvf door operator schematic diagram
(below shown is left opening)
识别号: omj-200b 轿架直梁安装) omj-200a( 轿顶安装)
serial no: omj-200b(straight beam installation) omj-200a(car top installation)
轿架直梁安装: omj-200b / straight beam installation
门控制器配置（选配）
 |  |  |
| olvf200-1 | nice-d-a-sop4-ol2 | aad03040d-ol |
安装方式附件配置
1、轿顶安装for car top installation | |||
 |  |  | |
1.1 轿顶安装支架 installation brackets drawing no: m1002042 | 1.2 加强安装支架 strengthened installation bracket drawing no:m1002046 | 1.3 轿顶安装c 型管( 选配) fixing pipe for car top installation(optional) drawing no: omj01-03 | |
| 3、轿架直梁安装 for straight beam installation | |||
 |  |  |  |
3.1 安装臂组件 installation arm module drawing no:m1002001 | 3.2 直拉杆组件/ 长拉杆组件 straight tie-rod module / long tie-rod module drawing no:m1002015/m1002012 | 3.3 大拉钩/ 小拉钩 big pull hook / small pull hook drawing no:m1002018/m1002021 | 3.4 安装侧板组件 side bracket for installation drawing no:m1002025 |
