识别号：omj-05x(125 型地坎 ) omj-05ax(96 型地坎 )
特 征：1.采用一级减速同步带传动 , 无滑差 , 无需润滑 , 运行平稳噪音更低
2.采用集成轿门锁功能的异步门刀 , 实现门挂板上安装 , 符合新国标要求
3.采用 vvvf 变频控制技术 , 调试简便 , 安全可靠
serial no：omj-05x(with sill in 125mm width) omj-05ax (with sill in 96mm width)
feature：1.the synchronous belt drive directly, no slip, no lubrication, running smoothly in lower nois
2.the asynchronous vane is equipped with door lock function, installation on door hanger, and qualified by new national standard
3.vvvf control system, safe, reliable, easy to adjust
omj 系列 中分双折三相变频异步门机 ( 轿架直梁安装 ) 示意图
4-leafs center opening vvvf door operator(straight beam installation)schematic diagram
|
|
|
| 变频器 ( 可选 ) installation stand drawing no:nice-d-a-sop4-ol2 | 松下同异步一体 drawing no:aad03040d | 松下 drawing no:aad03011dk |
1、轿架直梁安装 for straight beam installation
 |  |  |  |
1.1 安装臂组件 installation arm module drawing no: omj05.5c | 1.2 直拉杆组件 / 长拉杆组件 straight tie-rod module / long tie-rod module drawing no:omj02.6 / omj02.5 | 1.3 大拉钩 / 小拉钩 big pull hook / small pull hook drawing no: omj01.26 / omj01.32 | 1.4 安装侧板组件 side bracket for installation drawing no: omj05.1.1.1-2 |
2、轿顶安装for car top installation
 |  |  |
轿顶安装支架 car top installation brackets | 轿顶安装c 型管( 选配) fixing pipe for car top installation(optional) drawing no: omj01-03 | 加强安装支架 strengthened installation bracket drawing no: omj05jd-1b |
