识别号：ocm-110d( 聚胺脂门挂轮)

特 征：1、开锁方式为门套上开锁，通过45kg 摆锤冲击试验

          2、采用拉簧式强迫关门方式，拉簧置于层门装置内上侧

          3、门锁通过国家电梯检测中心测试合格

          4、可配用有框玻璃门板

          5、门锁适用电压：≤ ac230v、≤ dc110v

serial no:ocm-110d (with polyurethane wheels)

feature:1、 unlocking hole on landing panel, passed 45kg pendulum impact test

           2 、closing by spring type, spring assembled on inner top of landing device

           3 、door lock qualified by the national elevator inspection center

           4、 suitable for glass door panels

           5 、voltage for door lock: ≤ ac230v, ≤ dc110v

ocm 系列 中分式层门装置( 拉簧式强迫关门) 安装示意图

2-leafs center opening landing door device (common spring type)

installation schematic diagram

识别号:ocm-110d( 聚胺脂门挂轮)

serial no:ocm01-c (with polyurethane wheels)

主要附件图/ accessories:

上坎安装架 installation stand drawing no:a1066e 100.7	拉簧组件 spring module drawing no:c1100019	层门小封包 fixings drawing no:c1101001
