识别号：omj-06jdx
特 征：1.采用一级减速同步带传动 , 无滑差 , 无需润滑 , 运行平稳噪音更低
2.采用集成轿门锁功能的异步门刀 , 实现门挂板上安装 , 符合新国标要求
3.采用 vvvf 变频控制技术 , 调试简便 , 安全可靠
serial no：omj-06jdx
feature：1.the synchronous belt drive directly, no slip, no lubrication, running smoothly in lower nois
2.the asynchronous vane is equipped with door lock function, installation on door hanger, and qualified by new national standard
3.vvvf control system, safe, reliable, easy to adjust
omj 系列 旁开双折三相变频异步门机 ( 轿顶安装 )示意图 ( 图示为左开门 )
2-leafs side openingvvvf door operator(car top installation)schematic diagram(below shown is left opening)
|
|
|
|
| 变频器 ( 可选 ) installation stand drawing no:nice-d-a-sop4-ol2 | 松下同异步一体 drawing no:aad03040d-ol | ( 集成轿门锁 ) 门刀组件 (with door lock function) door vane module drawing no:omj09x.2 | 锁盒组件 lock box module drawing no:omj09x.1.12 |
 |  |  | |
| 门机小零件组件 door operator fixings drawing no:omj02.3 | 门刀安装座 stand for door vane drawing no:omj06x.1.6 | 皮带轮 belt pulley drawing no: omj09x.1.7-1 | 轿顶安装 c 型管 ( 选配 ) fixing pipe for car top installation(optional) drawing no:omj01-03 |
 | |||
| 轿顶安装支架 installation brackets drawing no:omj01-01 / omj01-02 |
