技术参数 /technical specifications：
型号 / type: xs260
1.额定速度 :v= 0.25~1.75 m/s
2.钢丝绳直径 :φ8 mm
3.绳轮节圆直径 :φ240 mm
4.涨紧力 :500~1000 n
1.rated speed:v= 0.25~1.75 m/s
2.rope dia:φ8 mm
3.sheave diameter:φ240 mm
4.rope tension force:500~1000 n
型号 / type: xs260a
1.额定速度 :v= 0.25~1.75 m/s
2.钢丝绳直径 :φ6mm
3.绳轮节圆直径 :φ200 mm
4.涨紧力 :500 ~1000 n
1.rated speed:v= 0.25~1.75 m/s
2.rope dia:φ6mm
3.sheave diameter:φ200 mm
4.rope tension force:500~1000 n
产品说明 / description:
1、此限速器适用于配置电磁式夹绳器，能装在电梯机房上或井道内。
2、此限速器适配于 zj260 或 zj260a 涨紧装置；
3、电磁铁开关用于电梯检测时远程控制使限速器发生机械动作；
4、电气开关连接安全回路，动作后可以远程控制复位。
1.this governor is adapted to electromagnetic rope gripper and can be installed in machine room or hoistway
2.the governor is matching to zj260 or zj260a tensioning device;
3.solenoid switch is used to issue starting command to governor by remote control during lift inspection
4.electrial switch connected with safety circuit , can reset the governor by remote control after action
限速器附件 / governor attachment:
限速器系统安装示意图
governor system installation diagram
